Details
Made to go up the mountain in a hurry, and down the mountain even faster. The all new Genius ST features a custom Float X Nude shock from FOX and is the perfect bike for those who have an insatiable hunger for rippin&, 39- trail.
Please note that bike specifications are subject to change without prior notice.
Key Features
- Genius Carbon HMF-Alloy Frame
- FOX 36 P. Elite Grip2 160mm Fork
- FOX Float X Nude, TracLoc, 150mm
- SRAM GX Eagle AXS Transmission
- Shimano XT 4 Piston Disc Brakes
- Syncros Revelstoke 2.0 TR Wheels
- Maxxis Foldable Tires
- Syncros Dropper Post and CF parts
Max. System Weight 128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Frame Size | Small | Medium | Large | X-Large |
---|---|---|---|---|
Head tube angle | 63.9 ° | 63.9 ° | 63.9 ° | 63.9 ° |
Head tube length | 90.0 mm | 100.0 mm | 120.0 mm | 135.0 mm |
Top tube horizontal | 570.1 mm | 602.2 mm | 631.3 mm | 659.3 mm |
Standover height | 728.5 mm | 738.5 mm | 753.5 mm | 768.5 mm |
BB offset | -33.0 mm | -33.0 mm | -33.0 mm | -33.0 mm |
BB height | 342.5 mm | 342.5 mm | 342.5 mm | 342.5 mm |
Wheel base | 1,195.0 mm | 1,229.0 mm | 1,263.0 mm | 1,294.0 mm |
BB center to top of seattube | 380.0 mm | 410.0 mm | 440.0 mm | 470.0 mm |
Seat angle | 76.8 ° | 77.1 ° | 77.2 ° | 77.4 ° |
Chainstay | 440.0 mm | 440.0 mm | 440.0 mm | 440.0 mm |
Reach | 430.0 mm | 460.0 mm | 485.0 mm | 510.0 mm |
Stack | 617.0 mm | 626.1 mm | 644.2 mm | 657.8 mm |
Stem length | 40.0 mm | 40.0 mm | 40.0 mm | 40.0 mm |
Trail | 125.8 mm | 125.8 mm | 125.8 mm | 125.8 mm |
Fork length | 571.0 mm | 571.0 mm | 571.0 mm | 571.0 mm |
Maximum Seatpost Insertion | 173.0 mm | 204.0 mm | 234.0 mm | 265.0 mm |
Crank Length | 170.0 mm | 170.0 mm | 170.0 mm | 170.0 mm |
Specs
Frame | Genius Carbon HMF Mainframe with Alloy 6061 Swingarm Integrated Suspension Technology Virtual 4 Link kinematic / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline |
---|---|
Fork | FOX 36 Float Performance Elite Grip 2 Air HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle 44mm offset / tapered steerer 160mm travel |
Rear Shock | FOX Float X NUDE PE EVOL Piggy Back Trunnion SCOTT custom w. travel / geo adj. 3 modes: Climbing-Traction Control-Descend Custom large air volume / Comp & Reb. Adj. Travel 150-100-Climbing / T185X55mm |
Wheels | Syncros Revelstoke 2.0 6 Bolt F: 15x110mm R: 12x148mm 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with 6mm Allen T30 and T25 Tools |
Tires |
Front: Maxxis Minion DHF / 2.6" / 120TPI Foldable Tubeless Ready / EXO 3C maxx Terra Rear: Maxxis Dissector / 2.6" / 60TPI Foldable Tubeless Ready / EXO 3C maxx Terra |
Bottom Bracket | SRAM DUB PF 92 MTB Wide / shell 41x92mm |
Crankset | SRAM GX Eagle Transmission Bash guard / DUB / 55mm CL / 32T |
Shifters | SRAM GX Eagle AXS Rocker Controller |
Rear Derailleur | SRAM GX Eagle AXS Transmission 12 Speed Wireless Electronic Shift System |
Cassette/Freewheel | SRAM GX Eagle XS 1275 Transmission 10-52 |
Chain | SRAM CN GX Eagle Transmission |
Brakes | Shimano XT M8120 4 Piston Disc |
Rotors | Shimano SM-RT76 / 6 Bolt / 203/F and 180/R |
Handlebars | Syncros Hixon iC Carbon Size S & M 15mm rise / Size L 25mm rise back sweep 8° / 780mm Syncros Endurance lock-on grips |
Headset | Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB |
Seatpost | Syncros Duncan Dropper Post 1.5 31.6mm / S size 140mm / M size 160mm L size 170mm |
Saddle | Syncros Savona 2.0 V-Concept CrMo rails |
Pedals | Sold Separately |
Accessories & Extras |
TracLoc Technology Rear Suspension & Dropper Remote 3 Rear Suspension modes SRAM AXS Powerpack Syncros Fork Fender |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
Prism Unicorn Purple / Large / 29-inch | 196530174851 | 420649010 |
