Details
The Scale RC SL is the perfect blend of stiffness, lightweight, and 30 years of carbon expertise. These characteristics, encompassed in an uncompromising frame design decisively accelerate the Scale away from the pack with every pedal stroke. Whenever you find yourself up against the clock, tip the scales in your favor. Please note that bike specifications are subject to change without prior notice
Key Features
- Scale Carbon HMX SL Frame
- FOX 32SC Float Factory 100mm Fork
- RideLoc 2 / 3-Position Remote
- SRAM XX SL AXS TR, PWR Meter
- Trickstuff Piccola Disc Brakes
- Syncros Silverton SL2 CF Wheels
- Maxxis Rekon Race Foldable Tires
- Syncros Carbon Parts
Max. System Weight 128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Frame Size | Small | Medium | Large | X-Large |
---|---|---|---|---|
Head tube angle | 67.9 ° | 67.9 ° | 67.9 ° | 67.9 ° |
Head tube length | 90.0 mm | 95.0 mm | 110.0 mm | 120.0 mm |
Top tube horizontal | 575.0 mm | 600.2 mm | 626.0 mm | 656.5 mm |
Standover height | 752.0 mm | 781.0 mm | 800.0 mm | 835.1 mm |
BB offset | -62.0 mm | -62.0 mm | -62.0 mm | -62.0 mm |
BB height | 313.0 mm | 313.0 mm | 313.0 mm | 313.0 mm |
Wheel base | 1,105.4 mm | 1,131.1 mm | 1,158.0 mm | 1,189.4 mm |
BB center to top of seattube | 390.0 mm | 440.0 mm | 480.0 mm | 530.0 mm |
Seat angle | 75.4 ° | 75.4 ° | 75.3 ° | 75.3 ° |
Chainstay | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm |
Reach | 418.5 mm | 442.3 mm | 463.6 mm | 491.2 mm |
Stack | 600.3 mm | 604.9 mm | 618.9 mm | 628.1 mm |
Stem length | 50.0 mm | 60.0 mm | 70.0 mm | 80.0 mm |
Trail | 105.1 mm | 105.0 mm | 105.0 mm | 105.0 mm |
Specs
Frame | Scale Carbon HMX SL Adjustable head angle / Syncros Cable Integration System Advanced Shock & Standing Damping System BB92 / UDH Interface / 12x148mm with 55mm Chainline |
---|---|
Fork | FOX 32 SC Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle / 44mm offset Tapered steerer / Lockout / Reb. Adj. 100mm travel |
Wheels | Syncros Silverton SL2-30 CL full Carbon F: 15x110mm R: 12x148mm / 30mm Tubeless ready rim DT Swiss 240 Ratchet EXP 36 / XD Driver SRAM TyreWiz / Syncros SL Axle w/Removable Lever with 6mm Allen T30 and T25 Tools |
Tires | Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead Tubeless Ready / EXO |
Bottom Bracket | SRAM DUB PF 92 MTB / shell 41x92mm |
Crankset | SRAM XX SL Eagle AXS Transmission Carbon crankarm / Spider Power Meter DUB / 55mm CL / 32T |
Shifters | SRAM AXS Rocker Controller |
Rear Derailleur | SRAM XX SL Eagle AXS Transmission 12 Speed Wireless Electronic Shift System |
Cassette/Freewheel | SRAM XX SL Eagle XS 1299 Transmission 10-52 |
Chain | SRAM CN XX SL Eagle Transmission |
Brakes | Trickstuff Piccola Carbon Disc |
Rotors | Trickstuff Dächle Ultra-Light / 180/F and 160/R |
Handlebars | Syncros Fraser iC SL XC Carbon -12° rise / back sweep 8° / 740mm Syncros Performance XC lock-on grips |
Headset | Syncros - Acros Angle adjust & Cable Routing HS System Stainless +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB |
Seatpost | Syncros Duncan SL Carbon 10mm offset / 31.6x400mm |
Saddle | Syncros Belcarra SL Regular 1.0 Carbon rails |
Accessories & Extras |
SCOTT RideLoc 2 Technology 3 Suspension modes SRAM AXS Powerpack SRAM TyreWiz Trickstuff Bleed Kit |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
Carbon Black / Small / 29-inch | 196530176305 | 420878006 |
Carbon Black / Medium / 29-inch | 196530176312 | 420878008 |
Carbon Black / Large / 29-inch | 196530176329 | 420878010 |
Carbon Black / X-Large / 29-inch | 196530176336 | 420878012 |
