Syncros Headset Cups - ZS56 Reach Adjust, 5mm

Change your bikes geometry to suit you - with our World Cup proven angle headsets you can alter stock geometry, changing the way your bike rides and feels to better match your personal riding style.

This Reach ZS56 EC56 headset allows you to slacken your bikes head angle to gain more stability or steepen your bikes head angle if you are looking to sharpen your bikes steering.


This headset will allow you to alter your top-tube length by +/- 5mm.

Fits headtube internal diameter: Upper - 56mm: ZS56
Fits headtube internal diameter: Lower - 56mm: EC56

Upper cup insertion depth: 11.5mm
Lower cup insertion depth: 11.5mm

Upper cup Stack height: 3.5mm - Total upper stack height including bearing cover: 9.5mm
Lower cup Stack height: 14mm

Upper Bearing: 41mm OD, 45 x 45 Degree AC sealed bearing
Lower Bearing: 52mm OD, 45 x 45 Degree AC sealed bearing

To suit tapered forks.
