Trek Rail 9.8 XT

Trek Rail 9.8 XT
  • Color: Gloss Purple Phaze/Matte Raw Carbon
  • Color: Solid Charcoal to Root Beer Ano Decal
  • Color: Solid Charcoal/Radioactive Orange
$7,999.99
Please select options

Details

Rail 9.8 is a long-travel carbon electric mountain bike that gets you to the fun stuff faster. It features an upgraded fork, drivetrain, and dropper for exceptional performance on the gnarliest runs. This e-MTB feels and rides just like our rowdiest trail bikes, and it's built with the same trail-specific tech. The difference is that the powerful new Bosch drive system zips up climbs so you can spend less time grinding and more time getting rad.

It's right for you if...
You're looking for a long-travel carbon e-MTB with high-performance parts. You crave the responsiveness of carbon, the plush feel of high-end suspension, and would rather get all the good stuff now than have to upgrade down the line.

The tech you get
A light and durable OCLV Mountain Carbon main frame with alloy stays that fully encases a 625Wh battery for sleek looks and protection on the trail, a 160mm RockShox Lyrik Select Plus fork with Charger 2.1 RC damper, 150mm of rear travel with a RockShox Deluxe RT3 shock with Trek's RE:aktiv with Thru Shaft damper, a powerful new Bosch Performance Line CX 250W motor that assists up to 20 mph, and a Purion controller. A 1x12 Shimano XT drivetrain, Bontrager Line Elite dropper post, 4-piston brakes, a carbon handlebar, and Bontrager Line Comp 30 29er wheels with Bontrager SE5 Team Issue tires.

The final word
This bike features across-the-board upgrades that make it a seriously capable high-performance ripper. It's built for hammering gnarly descents, then flying right back up again thanks to the powerful Bosch drive system.

Why you'll love it
- The new, better-than-ever Bosch motor is smaller, lighter, and more efficient. It feels more natural while you're pedaling, and has less drag when you're not
- Rail shreds just as hard as its non-electric brethren, plus it powers you right back up the mountain-no shuttle or lift necessary
- Trek's Removable Integrated Battery (RIB) system looks great and is super user-friendly: it fully hides the battery in the frame for protection, makes it easy remove the battery without tools and lets you mount a water bottle cage
- RE:aktiv with Thru Shaft works faster than a normal shock, so it tracks the ground better and keeps you in control
- Made with the same exclusive frame tech as Remedy and Slash, like Mino Link adjustable geometry, a Straight Shot down tube for extra stiffness, and Active Braking Pivot (ABP)

Dropper posts

A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.

Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.

Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.

Specs

Motor NEW Bosch Performance CX, magnesium motor body, 250 watt, 75 Nm, 20 mph max assist
Battery Bosch PowerTube 625
Display Bosch Purion
Max Assisted Speed 20 mph
Frame OCLV Mountain Carbon main frame & stays, Removable Integrated Battery (RIB), tapered head tube, Knock Block, Control Freak internal routing, magnesium rocker link, Motor Armor, Mino Link, ABP, Boost148, 12mm thru axle, 150mm travel
Fork RockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, e-MTB optimized, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 160mm travel
Headset Knock Block Integrated, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Rear Shock RockShox Deluxe RT3 shock with Trek's RE:aktiv with Thru Shaft damper
Rims/Wheels Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Shimano MicroSpline freehub, Boost 110 front, Boost 148 rear
Tires Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.60"
Crankset Ethirteen Race Alloy, 36T
Chainrings 36T
Chain Shimano XT M8100, 12 speed
Rear Derailleur Shimano XT M8100, Shadow Plus, long cage, 51T max cog
Cassette/Rear Cogs Shimano XT M8100, 10-51, 12 speed
Shifters Shimano XT M8100, 12 speed
Handlebars Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise
Tape/Grips Bontrager XR Trail Elite, alloy lock-on
Stem Bontrager Line Pro, 35mm, Knock Block, 0 degree
Brakes Shimano SLX M7120 4-piston hydraulic disc
Pedals VP-536 nylon platform
Saddle Bontrager Arvada, austenite rails, 138mm width
Seatpost Bontrager Line Elite Dropper, internal routing, 31.6mm

* Subject to change without notice.

Videos

Part Numbers

Option UPC MPN Store SKU
Gloss Purple Phaze/Matte Raw Carbon / Small 601842337851 598230 RAI41866430N
Gloss Purple Phaze/Matte Raw Carbon / Medium 601842337868 598231 RAI41478458N
Gloss Purple Phaze/Matte Raw Carbon / Large 601842337875 598232 RAI41403112N
Gloss Purple Phaze/Matte Raw Carbon / X-Large 601842337882 598233 RAI42487545N
Solid Charcoal to Root Beer Ano Decal / Small 601842337936 598238 RAI42783044L
Solid Charcoal to Root Beer Ano Decal / Medium 601842337943 598239 RAI42479050L
Solid Charcoal to Root Beer Ano Decal / Large 601842337950 598240 RAI42853209L
Solid Charcoal to Root Beer Ano Decal / X-Large 601842337967 598241 RAI43346699L
Solid Charcoal/Radioactive Orange / Small 601842337899 598234 RAI41514799E
Solid Charcoal/Radioactive Orange / Medium 601842337905 598235 RAI41639981E
Solid Charcoal/Radioactive Orange / Large 601842337912 598236 RAI41500230E
Solid Charcoal/Radioactive Orange / X-Large 601842337929 598237 RAI42630994E
